SAB GOBLIN 700 Sport Havok Edition (WITH MAIN AND TAIL BLADES)

The Goblin 700 Sport Havok Edition is the Goblin Competition Carbon Edition with 3 blades Head and Tail system in Black anodizing color


General Specifications:

    Main rotor diameter:  1568 mm (with 690 mm blades)
    HPS3 Head
    Main blade length: 690-710 mm
    Tail rotor diameter: 305 mm
    Tail blade length: 115 mm
    Main shaft diameter: 12 mm
    Tail shaft diameter: 6 mm
    Spindle shaft diameter: 10 mm
    Gear Ratios 8.6-11.9 : 1
    Weight including electronics: 3620 g (excluding flight battery).
    22T motor pulley included (other pulley sizes available)
    All pulleys are made for 6 and 8 mm motor shaft



Electronic Specifications:

    Cyclic Servos: Standard size (40mm)
    Tail Servo: Standard size (40mm)
    Typical Speed Controller: 120-160A
    Motors: (Max Diameter: 64 mm, Max Height: 64 mm)
    Battery compartment: until 75x58x350mm
