Xnova 50XX-530kv TAREQ special edition

Xnova TAREQ_special_edition  brushless high performance outrunner motor designed for 12S and 14S absolute crazy power 3D flying, from 700 and up to 800mm size helicopter where highest power to weight ratio is important. One of the most powerfull motors currently available.


Slots & Poles  12s10p
Winding T  YY
rpm/V  530
Volt (V)  20 | 40 | 45
Io(A)  4.5 | 7.5 | 8.1
Rm (mohm)  6.2| 6.2 | 6.2
Weight (without connector) (g)  640
Body Length (no shaft) mm  61.5
Diameter (mm)  63
Shaft Length (mm) (Details pictures)  | 32 | 61
Shaft Dia. (mm)  8 |
Mounting Holes CTC Distance (mm)  30
Mounting Screw  M4
Max Eff. Curr. A  120.48 | 219.97
Max Eff.  92.67 | 93.30
Kt (Nm/A  0.0180
Km (Nm/sqrt(w))  0.2288
Max Continuous Power(Watts)  8000
Peak Continuous Power(Watts) (5 sec)  13000 (5sec)
